Two backlit LCDs for rotation speed and time setting. Rotation speed and time values are displayed simultaneously. Electronic setting of rotation speed and time parameters.
Non-commutator motor extends the device service life and eliminates the magnetic interference influence. The motor is protected from overload.
| Shaking type | Orbital |
|---|---|
| Oscillation amplitude, mm | 10 |
| Maximum shaking weight (with platform), kg | 7,5 |
| Speed range, rpm | 100 – 500 |
| Speed increment, rpm | 10 |
| Timer, minutes | 1-1199 |
| Controller | digital |
| Motor type | Non-commutator motor |
| Exterior dimensions (LхWхH), mm | 420х370хh100/ h210 with platform |
| Weight (without platform), kg | 13,5 |
| Platform dimensions, mm | 310х310х110 |
| Platform weight, kg | 1,5 |
| Protection class | IP21 |
| Interface | RS232 |
| Power supply, Hz | 200-240 В/50-60 Hz |
| Power, W | 30 |
| Shipping dimensions | 2 places |
| Device | 530х490х180 mm |
